Online Medicine Bottle Rotary Checkweigher Automtic Conveying Check Weigher

Online Medicine Bottle Rotary Checkweigher Automtic Conveying Check Weigher

The automtic bottle rotary conveying checkweigher adopts a turntable structure design, and can work with high precision through the newly developed weighing sensor and ultra-high-speed processing module. Using this online medicine bottle rotary checkweigher, which can be easily integrated into the production line, you can minimize the loss of materials above the specified weight and help reduce production costs.

tag:

Description

Online Medicine Bottle Rotary Checkweigher Automtic Conveying Check Weigher

The automtic bottle rotary conveying checkweigher adopts a turntable structure design, and can work with high precision through the newly developed weighing sensor and ultra-high-speed processing module. Using this online medicine bottle rotary checkweigher, which can be easily integrated into the production line, you can minimize the loss of materials above the specified weight and help reduce production costs. Any OEM and customer design orders are welcome! If you are interested in our products, please feel free to contact us.

Automtic bottle rotary conveying checkweigher pictures

Bottle Automtic Conveying Check Weigher

Online Medicine Bottle Rotary Checkweigher

Medicine Bottle Rotary Checkweigher

Model SG-Z1

Weighing range 5-300g

Minimum scale 0.01g

Maximum sorting speed 50 pieces/minute (one channel)

Conveying speed 20-100m/min

Operation mode Touch type operation

Conveying direction facing the touch screen from left to right

Removal method: air blowing removal/push plate removal

Belt height from the ground 750 ± 50mm (customizable according to customer requirements)

Machine structure stainless steel (SUS304)

Power supply 220V 50-60HZ

Power: about 300W

Windshield thick acrylic (to avoid airflow interference)

Working environment temperature: 0 ℃~40 ℃, humidity: 30%~95%

Note: Due to the different properties and usage environments of the tested product, the detection speed and accuracy are also different, and the actual test is taken as the standard.


Online Medicine Bottle Rotary Checkweigher Automtic Conveying Check Weigher


•Easy Integration: adjustable height, modular design

•Sturdy and robust construction: Stainless Steel 304

•Easy to use: touch screen operating system is easy to use with user password protection

•Easy to clean: detachable belt easy to to take apart for cleaning and set up.

•Variable Speed: Speed configurable based on application

•High Speed and Accuracy: equipped with high grade sensor and load cell with ultra fast processor for excellent accuracy and speed

•Zero Trace: Manual and Automatic Calibration, increase accuracy

•Report and Data Exportation: Built-in real time report, exportable to Excel file, storing up 1 year production data in USB disk

•Connectivity: standard ports for data exportation and connect to PC

•Self-learning: no need to calibration, system will find the best set up for the product. Configurable up to 2000 product settings

•Different Detection Modes: Default Mode, Static Mode, Power saving mode

•Faulty report: The system can detect and report faulty part of the system makes it easy to diagnose problems

•Output Ports: RS-485 and RS-232, able to Connect with printers and label machines

The automtic bottle rotary conveying checkweigher adopts a turntable structure design, which is compact and space-saving. It is suitable for bottled products in many industries such as medicine, food, beverage, daily chemical, etc.

Automtic bottle rotary conveying checkweigher manufacturers offer a wide range of customization options to tailor the design, functionality and specifications of a bottle rotary checkweigher system to meet the specific needs and requirements of OEM/ODM customers.

Customization options may include conveyor configuration, reject mechanisms, weighing capabilities, software functionality, user interface and integration capabilities.


Online Medicine Bottle Rotary Checkweigher Automtic Conveying Check Weigher

Equipment packed in export standard wooden cases (fumigation-free). We can accept FOB, CFR, CIF terms, and our professional logistics team can handle sea, air, and rail transportation.

1. Pre-sales consultation

We will help you customize the appropriate bottle rotary conveying checkweigher solutions according to your requirements and specific circumstances.

2. Installation service

We will dispatch professional technicians to perform on-site installation and commissioning as needed.

3. Maintenance service

Shigan provides long-term maintenance services, providing any repair parts free of charge during the warranty period, and only charges after the warranty period expires.

4. Employee training

Shigan provides free technical training for our customers to fully master the correct product maintenance technology.
