A high speed checkweigher is a machine for (in-line) online weighing of single packaged products. It is usually used at the middle or end of the assembly line. It performs weight detection on semi-finished products and finished products. Products that do not meet the set weight (or weight deviation) will be automatically rejected. The speed of a waterproof dynamic checkweigher depends on the size of the product being weighed and the acceptable error (accuracy) range.

tag:

Waterproof Customized High Performance Checkweigher Hi-speed Check Weighing Scale Conveyor Belt Weighers


Product Description

Automatic checkweigher as inline check weigher, dynamic check weighing machine, online weight sorting machine, weight checker, weighing scale and etc,.

A high speed checkweigher is a machine for (in-line) online weighing of single packaged products. It is usually used at the middle or end of the assembly line. It performs weight detection on semi-finished products and finished products. Products that do not meet the set weight (or weight deviation) will be automatically rejected. The speed of a waterproof conveyor belt checkweigher depends on the size of the product being weighed and the acceptable error (accuracy) range. The automatic checkweigher system can also be equipped with additional detection devices, such as metal detectors and X-ray machines, which can simultaneously realize multiple property detections to eliminate defective products and ensure product quality multiple times.For further information about our services, or if you would like one of our professionals to contact you, please contact us.


Hi-speed Check Weighing Scale

Waterproof Customized High Performance Checkweigher


Specification Parameter

Type SG-220

Weighing Range 5-1500g

Limited of product L: 300 W:220 H: 3-200mm

Accuracy ±0.2g Depends on product

Division Scale 0.1g

Belt Speed 0- 60 m/min

Max Speed 100 pcs/min

Belt Width 220mm

Machine Weight 60kg+44kg

Power Supply AC 110/220V ±10% 50HZ

Power 100W

Main Material SU304 stainless steel



Shanghai Shigan provides hi-speed checkweigher solutions. Dynamic checkweighers have complete specifications and support full-featured customized services. The automatic checkweigher can replace manual sorting and realize intelligent standardized automatic weighing and sorting specifications.


How to choose products?

1. Determine the series according to the size, weight range and use of the products you need to sort.

If the weight is less than 300g, the size is 150*90*30mm, the model SG-150 is selected, and the belt width is 150mm and the range is less than 500g.


2. Determine the grade you need to sort, whether it is three grades or five grades, the price is different for different grades, the more grades, the higher the price. Currently our factory can sort up to 12 grades.


3. Determine the height, width (if any) of your existing assembly line, and the usable space required by our company.


4. Determine the optional functions you need; such as USB storage data, real-time transmission of weight data, alarms, etc.


In order to provide more accurate parameters, plans and quotations, it is recommended that you contact the person in charge of our company to help you complete the selection.


Main Advantages

Rack and electric box: The rack is used to support other components of the sorting machine; the electric box has a built-in PLC, which analyzes, calculates and processes the weight data collected by the A/D module, and controls the action of the conveyor belt motor and sorting mechanism.

Buffer belt: transport the product to be tested, and let the product to be tested enter the weighing belt smoothly for weighing.

Sorting belt: transports the product under test to the sorting mechanism.

Touchscreen: The interface for the operator to interact with the machine.

Windshield: used to block the wind and reduce the influence of the environment on the weight data collected by the weighing belt.

Weighing belt: A/D module and weight sensor are installed inside to collect weight data.

Selection agency: Eliminate unqualified weight products.

Touchscreen: The interface for the operator to interact with the machine.

Rack and electrical box: The interface for the operator to interact with the machine. Rack and electric box: The rack is used to support other components of the sorting machine; the electric box has a built-in PLC, which analyzes, calculates and processes the weight data collected by the A/D module, and controls the action of the conveyor belt motor and sorting mechanism.

Weighing belt: responsible for weighing and transportation.

Sensor assembly: A/D module and weight sensor are installed inside to collect weight data.

Selecting parts: Eliminate unqualified weight products.


Package & Shipping

Packing Detail:

Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.

We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.



Delivery Detail :

Shipped in 20 days after payment





Application

The high speed checkweigher can be widely used for weight detection after packaging in food, pharmaceutical, chemical, textile, clothing, toys, rubber and other fields, and is the first choice for many industries.


Our Company



We are committed to providing quality products and services to our customers and society. - Shanghai Shigan Industrial Co,.Ltd


Shanghai Shigan has more modern working facilities and gained expertise and experience in various automatic weighing inspections. We are becoming a high-tech enterprise integrating R&D, production, marketing and service backup. The main products include digital metal detector,conveyor belt metal detector,automatic checkweigher metal dtector, checkweigher, high-speed and high-precision checkweigher and other complete line checkweighing solutions, which are widely used in snack food, puffed food, fresh frozen Food, agriculture, medical, chemical and hardware fields.






After Sale Serive

In the spirit of pursuing high-quality products and customer satisfaction, Shanghai Shigan Industrial Co,.Ltd solemnly promises you the principle of preferential price, thoughtful service and reliable product quality.


1.Product quality commitment:

(1). There are quality records and testing data for the manufacture and testing of products.

(2). For the inspection of product performance, we sincerely invite users to inspect the whole process and performance of the product in person. After the product is confirmed to be qualified, it will be packaged and shipped.


2. the product price commitment:

(1). Under the same competitive conditions, our company will sincerely provide you with a preferential price on the basis of not reducing the technical performance of the product or changing the product components.


3. Delivery time commitment:

(1). Product delivery time: as far as possible according to user requirements, if there are special requirements, it needs to be completed in advance, and strive to meet user needs.
